Aluminum alloy window screen is manufactured from aluminum or aluminum-magnesium alloy wire and formed into woven mesh. It is classified by mesh count, wire diameter, and surface finish. Aluminum alloy window screen is used for windows, doors, balconies, and ventilation openings. It offers lightweight structure, rust resistance, good airflow, and long service life. This screen is widely applied in residential, commercial, coastal, and high-humidity environments where corrosion resistance and durability are required.

Specifications

• Materials: Aluminum or aluminum-magnesium alloy wire.
• Mesh Count Range: 14 × 14 to 18 × 18 mesh.
• Wire Diameter: 0.18–0.30 mm, common 0.20 mm, 0.23 mm, 0.25 mm.
• Opening Size: Approximately 0.9–1.6 mm square openings.
• Weave Type: Plain weave square mesh structure.
• Roll Width: 0.6–1.5 m standard widths.
• Roll Length: 10 m, 20 m, 30 m per roll.
• Surface Treatment: Natural aluminum, epoxy coated, or powder coated.
• Processing Methods: Wire drawing, weaving, coating, cutting, edge trimming.
• Weight Range: Approximately 80–150 g/m².
• Service Temperature Range: –30 °C to +120 °C.
• Applications: Windows, doors, balconies, ventilation, residential and commercial use.
